Advanced Lithium Technology

The CES Innovation Awards are based upon descriptive materials submitted to the judges. CEA did not verify the accuracy of any submission or of any claims made and did not test the item to which the award was given.

Specification: AA

Input: 5V/0.45A
Output: 1.5V, 1A
Capacity: 1040 mAh
Charge Time: 2 Hours
Recharge Cycle: 500x

Specification: AAA

Input: 5V/0.16A
Output: 1.5V, 0.5A
Capacity: 450 mAh
Charge Time: 2 Hours
Recharge Cycle: 500x

No Leaking

No dangerous acid leakage or corrosion

Low Drain

Minimal self-discharge

Rapid Charging

Charges three times faster than traditional
(NiMH) rechargeable batteries

Peak Performance

Constant maximum energy output

Recharges To Full Capacity

Minimal capacity degradation during recharge

Charging Protection:

OVER VOLTAGE PROTECTION
Protection Voltage: 4.3±0.05V,
Released Voltage: 4.1±0.05V,
Protection Delay Time:1 20~180mS

UNDER VOLTAGE PROTECTION
Protection Voltage: 2.4±0.1V,
Released Voltage: 3.0±0.1V,
Protection Delay Time: 40~60mS

SHORT CIRCUIT PROTECTION
Protection Condition: External
short, Protection Delay Time: 60~90µs

OVER CHARGING VOLTAGE PROTECTION
Protection Current: 2.1~3.9A
(Vgs=3.5V), Released Current:
Reset by Charger Release,
Protection Delay Time 8~14ms

CURRENT CONSUMPTION
Release Condition: Open short
Circuit, Normal Mode: 20~40µA
(Typ.30uA), Sleep Mode: =1.5µA
(Under Voltage Protection)
